HGRL high frequency medium frequency furnace function features are as follows:
1. The load resonance circuit adopts series inverter design, the import main body supports, and the high frequency power supply runs statically.
2. Series inverter, rectifier without voltage regulation, power supply circuit and control loop is simple, low failure rate.
3.Constant power output, the main control board adopts digital circuit design, strong anti-interference.
| Medium frequency furnace description | Unit | HGRL-175/3 | HGRLc-200/3 | HGRL-250/3 |
|---|---|---|---|---|
| power | Kw | 175 | 200 | 250 |
| Input voltage | Vt | 380 | 380 | 380 |
| Input current | A | 265 | 340 | 380 |
| Input frequency | Hz | 50 | 50 | 50 |
| Output frequency | Hz | 3000 | 3000 | 3000 |
| Furnace capacity | Kg | 100 | 150 | 200 |
| Power supply size | mm | 2500×1000×1800 | 2900×1100×1800 | 2900×1100×1800 |
| Furnace size | mm | 600×650×650 | 720×720×750 | 850×800×800 |
| Melting time | min | 18~25 | 18~25 | 18~25 |
| Furnace number | 2 | 2 | 2 | |
| Weight | Kg | 1500 | 1700 | 1900 |
